| Ref. |
OEM Part # |
Hardin # |
Mallory # |
GLM # |
Other # |
Description |
Num Req. |
Superceded From |
Special Notes |
| 1 |
32-1743565 |
|
|
|
|
HOSE, (38.00 Inches Bulk), Cut As Required - Drive To Sea Water Pump |
1 |
|
Bravo Models |
| 1 |
32-865672079 |
|
|
|
|
HOSE, (96.00 Inches Bulk), Cut 48.00 Inches - Drive To Sea Water Pump |
1 |
32-1743579 |
Six Drive Models |
| 1 |
32-13556A1 |
|
|
|
|
HOSE KIT, (10.00 Feet), Cut As Required - Drive To Sea Water Pump |
1 |
|
Driveline Models |
| 2 |
54-180766 |
|
|
|
|
CLAMP, Worm Gear |
2 |
|
Driveline Models |
| 2 |
54-180766 |
|
|
|
|
CLAMP, Worm Gear |
14 |
|
Bravo Models |
| 3 |
32-849935 |
|
|
|
|
HOSE, Molded, Circulating Pump To Fuel Cooler |
1 |
|
|
| 4 |
32-8M0062665 |
|
|
|
|
HOSE, (48.00 Inches Bulk), Cut As Required |
1 |
32-5346170 |
|
| 5 |
32-844881 |
|
|
|
|
HOSE, Molded, Cooler To Cooler |
1 |
|
NOTE: This Hose Is Cut To Fit For Engines With Transmission Cooler |
| 6 |
32-848956 |
|
|
|
|
HOSE, Molded, Cooler To Tube |
1 |
|
|
| 7 |
22-13177 |
|
|
|
|
TUBE, Hose Attachment |
1 |
|
Non Power Steering Models |
| 8 |
32-840926 |
|
|
|
|
HOSE, Molded, Heat Exchanger To Cooler/Tube |
1 |
|
|
| 9 |
32-840924 |
|
|
|
|
HOSE, Molded, Heat Exchanger To Port Exhaust Header |
1 |
|
|
| 10 |
54-180768 |
|
|
|
|
CLAMP, Worm Gear |
2 |
|
|
| 11 |
| 32-840927 |
|
|
|
|
HOSE, Molded, Crossover To Circulating Pump |
1 |
|
|
| 12 |
54-180765 |
|
|
|
|
CLAMP, Worm Gear |
4 |
|
|
| 13 |
32-840925 |
|
|
|
|
HOSE, Molded, Heat Exchanger To Starboard Exhaust Header |
1 |
|
|
| 14 |
54-180764 |
|
|
|
|
CLAMP, Worm Gear |
4 |
|
|
| 15 |
32-842754 |
|
|
|
|
HOSE, Molded, Exhaust Header To Pipe |
2 |
32-849939001 |
|
| 16 |
54-180763 |
|
|
|
|
CLAMP, Worm Gear |
4 |
|
|
| 17 |
32-8424181 |
|
|
|
|
HOSE, Molded, Exhaust Header To Pipe |
2 |
|
|
