This Part has options, please click the button below to order.
516-9057 + Option(s) The latest in LED lit electronic switches from Bluewater Enterprises. These switches feature easily swappable buttons (sold separately) so you change functions easily. This version is sold without a wire harness for users who want to build their own wiring harnesses. See related parts. There are over 100 Switch Function Icons to choose from.
- 15 AMP Rating
- Multiple Switch Options
- 100 + Label Options
- Transparent and Laser Etched Button Logos available separately
- IP69K Waterproof Rated
- 316 Stainless Steel Body
- Electronic Actuator
- Mechanically rated for 50,000 cycles
- Switches are LED Backlit
- WIRE HARNESS IS NOT INCLUDED!
- Caution: Momentary switch applications controlling solenoids may require a 5 amp diode on the output wire of the switch in order to prevent damage to the mosfet switch circuit.
|
|
615-516-9053-4214 These are standard push button switches. They have standard brightness LED's. Switch and Harness ONLY. Limited quantities available. NAV function. Red LED on.
|
|
615-516-9055-2123 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. Mom On-Mom On-off function.
|
|
615-516-9060-2123-5 These are adjustable breaker switches pre set at 5 Amps. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. Momentary On -Momentary On-off function.
|
|
615-516-9060-2113-5 These are adjustable breaker switches pre set at 5 Amps. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. Momentary On-off function.
|
|
615-516-9060-3114-5 These are adjustable breaker switches pre set at 5 Amps. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. Nav / Anch function.
|
|
615-516-9055-1123 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. On-off function. Blue LED on.
|
|
615-516-9060-3113-5 These are adjustable breaker switches pre set at 5 Amps. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. On-On-off function.
|
|
615-516-9055-3113 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. On-On-off function.
|
|
615-516-9055-3115 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. On-On-off-both function.
|
|
615-516-9060-3115-5 These are adjustable breaker switches pre set at 5 Amps. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch ONLY. Buttons and wire harnesses sold separately, see related parts. Limited quantities available. On-On-off-Both function.
|
|
615-516-9053-2113 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch with FIXED Translucent button ONLY. Wire harnesses and Icons sold separately, see related parts. Limited quantities available. Momentary On-off function.
|
|
615-516-9053-3113 These are standard push button switches. They have standard brightness LED's, they will not match the brightness of newer model 516-9059 and 516-9060 series switches. Switch with FIXED Translucent button ONLY. Wire harnesses and Icons sold separately, see related parts. Limited quantities available. On-On-off function.
|
|
This Part has options, please click the button below to order.
516-770 + Option(s) Breakers - 5 to 30 AMP Versions
These breakers are the same units used in our engine harnesses. Be careful
not to exceed original amperage rating of your existing harness.
- Input voltage rating: 125/250VAC; 32/50VDC
-
Interrupting Capacity: 125/250VAC x 1,000A(UL 1077)
-
Typical life: 1,000 operations at 200% overload.
-
Insulation Resistance: >100MOHM (DC 500V)
-
Dielectric Strength: > 1,500VAC/min.
|
|
This Part has options, please click the button below to order.
516-1300 + Option(s) Available in clear and black. These boots add a soft touch to Bluewater circuit breaker buttons.
|
|
516-1300-700-0092 Half Toggle Switch Boots - Black
These weather tight rubber moisture seal boots offer protection and styling
for virtually any dash assembly while leaving the metal toggle exposed. 15/32" - 32 Threads
|
|
This Part has options, please click the button below to order.
516-919 + Option(s) The latest in LED lit electronic switches from Bluewater Enterprises. These switches feature easily swappable buttons so you change functions easily. This version is sold without a wire harness for users who want to build their own wiring harnesses. See related parts. There are over 100 Switch Function Icons to choose from.
- 15 AMP Rating
- Multiple Switch Options
- 100 + Label Options
- Laser Etched Logos available
- IP69K Waterproof Rated
- 316 Stainless Steel Body
- Electronic Actuator
- Mechanically rated for 50,000 cycles
- Switches are LED Backlit
- WIRE HARNESS IS NOT INCLUDED!
- Caution: Momentary switch applications controlling solenoids may require a 5 amp diode on the output wire of the switch in order to prevent damage to the mosfet switch circuit.
- When using translucent buttons, labels are sold separately here.
- NOTE: Momentary Switch should not be used as an Engine Start switch
|
|
This Part has options, please click the button below to order.
516-919 + Option(s) The latest in LED lit electronic switches from Bluewater Enterprises. These switches feature easily swappable buttons so you change functions easily. There are over 100 Switch Function Icons to choose from.
- 15 AMP Rating
- Multiple Switch Options
- 100 + Label Options
- Laser Etched Logos available
- IP69K Waterproof Rated
- 316 Stainless Steel Body
- Electronic Actuator
- Mechanically rated for 50,000 cycles
- Switches are LED Backlit
- Plug and Wire Harness with 12" wire lead INCLUDED.
- Caution: Momentary switch applications controlling solenoids may require a 5 amp diode on the output wire of the switch in order to prevent damage to the mosfet switch circuit.
- When using translucent buttons, labels are sold separately here.
- NOTE: Momentary Switch should not be used as an Engine Start switch
|
|
This Part has options, please click the button below to order.
516-923 + Option(s) The latest in LED lit electronic switches from Bluewater Enterprises. These switches have built in breakers which can be set at positions from 0 to 20 Amps. These switches feature easily swappable buttons so you change functions easily. There are over 100 Switch Function Icons to choose from, and for an extra touch, our 7/8" bezels fit these perfectly, see the related parts! The harness plug (sold separate) is easily removed for quick switch type changes and the connection is waterproof. The entire stainless steel switch body is threaded for use in dashes up to 1.5" thick.
- 20 AMP Rating (1 Channel), 10 AMP Rating (2 Channel)
- 8 programmable Amp positions: 3,5,6,7.5, 10, 15,20,0.
- Programmed by default at 5 Amp. We can factory reprogram for a small fee.
- Reprogramming only to be performed by authorized installers and dealers.
- Multiple Switch Options
- 100 + Label Options
- Switch button can be removed and replaced.
- 120A Inrush Surge Protection
- Laser Etched Logos available
- IP69K Waterproof Rated
- 316 Stainless Steel Body
- Electronic Actuator
- Mechanically rated for 50,000 cycles
- Switches are LED Backlit
- Plug and Wire Harness are NOT INCLUDED.
- Caution: Momentary switch applications controlling solenoids may require a 5 amp diode on the output wire of the switch in order to prevent damage to the mosfet switch circuit.
- NOTE: Momentary Switch should not be used as an Engine Start switch
|
|
This Part has options, please click the button below to order.
516-923 + Option(s) The latest in LED lit electronic switches from Bluewater Enterprises. These switches have built in breakers which can be set at positions from 0 to 20 Amps. These switches feature easily swappable buttons so you change functions easily. There are over 100 Switch Function Icons to choose from, and for an extra touch, our 7/8" bezels fit these perfectly, see the related parts! The harness plug is easily removed for quick switch type changes and the connection is waterproof. The entire stainless steel switch body is threaded for use in dashes up to 1.5" thick.
- 20 AMP Rating (1 Channel), 10 AMP Rating (2 Channel)
- 8 programmable Amp positions: 3,5,6,7.5, 10, 15,20,0.
- Programmed by default at 5 Amp. We can factory reprogram for a small fee.
- Reprogramming only to be performed by authorized installers and dealers.
- Multiple Switch Options
- 100 + Label Options
- Switch button can be removed and replaced.
- 120A Inrush Surge Protection
- Laser Etched Logos available
- IP69K Waterproof Rated
- 316 Stainless Steel Body
- Electronic Actuator
- Mechanically rated for 50,000 cycles
- Switches are LED Backlit
- Plug with wire connections is INCLUDED. No wire is included.
- Caution: Momentary switch applications controlling solenoids may require a 5 amp diode on the output wire of the switch in order to prevent damage to the mosfet switch circuit.
- NOTE: Momentary Switch should not be used as an Engine Start switch
|
|
