NXT1 Drive - Serial 0M954569 and Up - Driveline Kit (NXT1)

Section Drawing: (Hover or click to view larger)

Untitled Document
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
- 842064A02



DRIVELINE KIT, NXT1 - Complete 1

- 84-8M3000325



HARNESS ASSEMBLY, Extension 1

- 84-843203A04



HARNESS ASSEMBLY, Extension 1

- 45-842089T



SHAFT, Input 1 45-842089
- 842090



RETAINER, Input Shaft 1

- 10-41350



SCREW, (.437-14 x 2.50) Stainless Steel 1

- 12-842922



WASHER, (.450 x .750 x .060) Stainless Steel 1

- NSS



NOT SOLD SEPARATE, Installation Instructions 1
This Part is not sold separately
- 842064A01



TRANSOM KIT, NXT1 Driveline 1

- 16-57933



STUD, (.437-14/.437-20 x 2.190) 4

- 12-842922



WASHER, (.450 x .750 x .060) Stainless Steel 4

- 11-34933
676-9-72004

NUT, (.437-20) Stainless Steel 4

- 842064T01



HOUSING, Transom Support 1 842064001
- 45-842112



SHAFT, Input 1

- 23-8M0005859



SLEEVE 1

- 53-8M0005874



RING, Snap 1

- 22-328022



PLUG, Pipe (.125-27) Brass 3

- 25-846366



O-RING, (4.860 x .120) 1

- 847322A1



COVER ASSEMBLY, Input Shaft 1

- 26-846496



SEAL 1

- 31-847395T1



BEARING SET, Cup And Cone 1

- 53-847323



RING, Retaining 1

- 8M0050789



SPACER 1 847321
- 31-846477A1



BEARING SET, Cup And Cone 1
- 15-846430A1



SHIM SET 1
- 26-846497



SEAL 1
- 10-825427



SCREW, (.437-14 x 1.250) Stainless Steel 4
- 12-45176

700-28420
WASHER, (.453 x .812 x .105) Stainless Steel 4
