Bravo X One - Serial 0W250000 and Up - Sterndrive Unit Chart, Bravo I-II-III X (Gasoline)

Section Drawing: (Hover or click to view larger)

Untitled Document
Ref. OEM Part # Hardin # Mallory # GLM # Other # Description Num Req. Superceded From Special Notes
NS 5-5237100TP



STERNDRIVE, Bravo-I X (1.36:1 Ratio) 1

NS 5-5237200TP



STERNDRIVE, Bravo-I X (1.50:1 Ratio)


NS 5-5237300TP



STERNDRIVE, Bravo-I X (1.65:1 Ratio) 1

NS 5-5337400TP



STERNDRIVE, Bravo-II X (1.81:1 Ratio) 1

NS 5-5337600TP



STERNDRIVE, Bravo-II X (2.00:1 Ratio) 1

NS 5-5337500TP



STERNDRIVE, Bravo-II X (2.20:1 Ratio) 1

NS 5-5447400TZ



STERNDRIVE, Bravo-III X (1.81:1 Ratio) 1 5-5447400TP
NS 5-5447600TZ



STERNDRIVE, Bravo-III X (2.00:1 Ratio) 1 5-5447600TP
NS 5-5447610TZ



STERNDRIVE, Bravo III X ITS (2.00:1) 1 5-5447610TP
NS 5-5447500TZ



STERNDRIVE, Bravo-III X (2.20:1 Ratio) 1 5-5447500TP
NS 5-5J37100TP



STERNDRIVE, Bravo-I X (1.36:1) 1
(SEACORE)
NS 5-5J37200TP



STERNDRIVE, Bravo-I X (1.50:1) 1
(SEACORE)
NS 5-5J37300TP



STERNDRIVE, Bravo-I X (1.65:1) 1
(SEACORE)
NS 5-5K37400TP



STERNDRIVE, Bravo-II X (1.81:1) 1
(SEACORE)
NS 5-5K37600TP



STERNDRIVE, Bravo-II X (2.00:1) 1
(SEACORE)
NS 5-5L47400TP



STERNDRIVE, Bravo-III X (1.81:1) 1
(SEACORE)
NS 5-5L47600TP



STERNDRIVE, Bravo-III X (2.00:1) 1
(SEACORE)
NS 5-5L47500TP



STERNDRIVE, Bravo-III X (2.20:1) 1
(SEACORE)
NS 5-5447400TZ



STERNDRIVE, Bravo-III X (1.81:1) Dual Water Pick-Up 1
NS 5-5447600TZ



STERNDRIVE, Bravo-III X (2.00:1) Dual Water Pick-Up 1
NS 5-5447500TZ



STERNDRIVE, Bravo-III X (2.20:1) Dual Water Pick-Up 1
NS 5-5447610TZ



STERNDRIVE, Bravo III X ITS (2.00:1) Dual Water Pick-Up 1
NS 5-5442100TZ



STERNDRIVE, Bravo-III X (1.36:1) Dual Water Pick-Up 1
