Bravo Plate Cooler Housing

Multi-Plate Race Style Oil Cooler Box Housing - NO COOLER ELEMENT

This multi-plate design oil cooler housing assembly is used in virtually every sever duty type of oil cooling environment found today. Recognized by Mercury Racing and every high profile professional engine builder as the most effective method to control oil temperature. This basically the same cooler package that's incorporated into a dual cooler style race bellhousing. Now you can have the same great cooling features in a remote mountable cooler. The cast aluminum housing features a hard anodized finish for corrosion resistance. Each housing has 1" NPT water inlets and outlets plus a dual-bolt mounting flange and will accept a 8,13 or 15 plate cooler assembly when used with the appropriate cover assembly.

Length 11-3/4", Height 5", and depth based on the 8 plate configuration is 4-3/8".
